Description

• Auto Test
• Built-in ELCB
• Line Fault indicator
• NTC Thermal Cut-Out
• Built-in auto flow sensor
• Double Copper Heating Element
• Splash-proof IP25 Standard
• Stepless Electronic Temperature Control
• 5 spray Pattern showerhead

Specification

• Application voltage : 230V±10%，Extreme conditions 260V
• Applicable air humidity : 50-98%RH
• Disconnect mode : Double Disconnection
• Strong Connection : Japan JST Connector
• Power Supply Voltage & Frequency (V/Hz) : 230V~,1Ph 50Hz
• Power Comsuption : 3300W
• Rated Current : 14.3A
• Minimum Inlet Pressure : 0.03MPa
• Maximum Inlet Pressure : 0.3MPa
• Max Outlet Water Temperature(°C) : 48℃
• Constant Temperature Performance : ±2℃
• Tank/heating element components Life Time : 6 years
• Minimum Flow Rate : 1.5L/min
• Operating Condition : Open type
• Pump : No
• Applicable Water Pressure : 0.03～0.3Mpa
• Feed Water Temperature : 5～40℃
• Applicable Feed Water : Tap water, TDS≤450mg/L
• Rated presssure : 0 MPa
• Inlet and Outlet pipe joint Dimension : G1/2″

Material

• Heating tube material : Copper
• Front Housing Materials(ABS/PP/HIPS) : ABS
• Back Base Materials (ABS/PP/HIPS) : ABS
• The Inlet / Outlet Pipe Materials : PA66 30%GF
• Water Proof Class : IP25
• Protection Class : Class I

Dimension

• Product Dimensions（mm） : 200*400*97 mm
• Packing Dimensions（mm） : 660*260*125 mm
• Outer Packing Dimensions（mm）: 675*520*280 mm
• Number of outer packing box : 4
• N.W.（kg） : 1.95
