Features

• Auto Test
• Built-in ELCB
• Line Fault indicator
• NTC Thermal Cut-Out
• Built-in auto flow sensor
• Double Copper Heating Element
• Splash-proof IP25 Standard

Specifications

• Application Voltage : 220v±10%，extreme Conditions 260v
• Applicable Air Humidity : 50-98%rh
• Disconnect Mode : Double Disconnection
• Strong Connection : Japan Jst Connector
• Power Supply Voltage & Frequency (V/hz) : 230v~,1ph 50hz
• Power Comsuption : 3300w
• Rated Current : 14.3a
• Minimum Inlet Pressure : 0.03mpa
• Maximum Inlet Pressure : 0.3mpa
• Max Outlet Water Temperature(°c) : 55℃
• Temperature Adjustable : Precise Temperature Control
• Tank/heating Element Components Life Time : 6 Years
• Rated Pressure : 0 Mpa
• Minimum Flow Rate : 1.5l/min
• Operating Condition : Open Type
• Applicable Water Pressure : 0.03～0.3mpa
• Feed Water Temperature : 5～40℃
• Applicable Feed Water : Tap Water, Tds≤450mg/l

Material

• Heating Tube Material : Copper
• Water Tank Material : Pa66 30%gf
• Front Housing Materials(Abs/pp/hips) : Abs
• Back Base Materials (Abs/pp/hips) : Abs
• The Inlet / Outlet Pipe Materials : Pa66 30%gf
• Water Proof Class : Ip25
• Protection Class : Class I

Dimension

• Product Dimensions（Mm） : 200*400*97 Mm
• Packing Dimensions（Mm） : 660*260*125 Mm
• Outer Packing Dimensions（Mm） : 675*520*280 Mm
